NavaSolar NV-BP18-1012 1kW Trolley Inverter – 960Wh LiFePO₄ Battery

IMPORTANT – Battery Runtime

The 960Wh battery capacity and 1000W inverter output describe different aspects of the system. Battery runtime depends on the power consumption of the connected appliances — higher loads will use the available battery energy more quickly.

For the best available runtime, ensure the unit is adequately charged before use. Actual runtime will vary according to the connected load and operating conditions.

All-in-One Energy Storage Solar System

The NavaSolar NV-BP18-1012 is an all-in-one backup power solution combining a 1000W pure sine wave inverter, 960Wh 12.8V 75Ah LiFePO₄ battery and built-in MPPT solar charge controller in a convenient trolley-style cabinet.

Ideal for providing backup power to essential household electronics, office equipment, appliances and other compatible loads during power interruptions.

Key Features
1000W rated pure sine wave inverter

960Wh LiFePO₄ battery

12.8V 75Ah battery capacity

4000+ rated charge cycles

Built-in MPPT solar charge controller

Up to 900W maximum solar input

24/7 UPS functionality

4 × 230V AC output sockets

2 × USB 5V outputs

1 × 12V DC output

Built-in protection against overcharge, over-current, short circuit, overload and over-temperature

Portable trolley design

Suitable for backup, home, office and off-grid applications

IMPORTANT – Battery Runtime
Battery backup time depends on the amount of power being used. The higher the load, the shorter the runtime. A 960Wh battery does not provide the same runtime at 100W, 500W and 1000W loads.
For best performance, fully charge the unit before first use and after significant use. Allow sufficient charging time for the battery to reach a full charge before relying on it for backup power. Connecting a high-power load to a partially charged battery will result in significantly shorter runtime.

The inverter has a maximum rated output of 1000W. The combined power consumption of connected appliances must remain within the inverter's rated capacity.

Inverter Specifications
Model: NV-BP18-1012
Rated Power: 1000W
Output Waveform: Pure Sine Wave
Output Voltage: 230V AC ±5%
Output Frequency: 50Hz / 60Hz ±0.2Hz
Peak Efficiency: 90%
Nominal DC Input Voltage: 12V DC ±0.3V
Standby Consumption: <25W
Solar / PV Input
Maximum Solar Input: 900W
Maximum PV Charging Current: 60A ±3A
Combined Charging Current: 70A ±4A
Maximum PV Open-Circuit Voltage: 105V DC
MPPT Voltage Range: 15–105V DC

Note: Connected solar panels must remain within the inverter's specified voltage and current limits.

AC Input
AC Input Voltage: 230V AC ±5%
Acceptable Input Voltage Range: 90–280V AC
Input Frequency: 50Hz / 60Hz, automatic detection
UPS Transfer Time: 10ms typical (UPS/VDE); 20ms typical (APL)
AC Charging
Charging Current: 10A / 20A ±4A
Charging Algorithm: 4-step lithium charging
Outputs
AC Output: 4 × 230V AC sockets
USB Output: 2 × 5V 2.4A USB ports
DC Output: 1 × 12V 1A port
Battery
Battery Chemistry: LiFePO₄ (Lithium Iron Phosphate)
Energy Capacity: 960Wh
Nominal Voltage: 12.8V
Capacity: 75Ah
Protection Board: 100A
Standard Charge/Discharge Current: 50A
Operating Temperature
Charging: 0°C to 45°C
Discharging: -10°C to 60°C
Dimensions & Weight
Product Dimensions: 37.9 × 25.4 × 49.9 cm (L × W × H)
Packaging Dimensions: 49.5 × 36.5 × 68 cm
Net Weight: 23 kg
Gross Weight: 32.8 kg
Safety & Protection

The integrated battery management and inverter protection systems help protect the unit against:

Overcharge
Over-current
Short circuit
Overload
Over-temperature

Please check the power requirements of your appliances before use. High-power appliances may significantly reduce battery runtime and some appliances may not be suitable for use with this 1000W inverter.

Battery Runtime Guide

Runtime depends on the total power consumption of your appliances. As a general guide, a fully charged 960Wh battery may provide approximately:

Load	Approx. Runtime*
100W	±8 hours
200W	±4 hours
300W	±2.5–3 hours
500W	±1.5–2 hours
800W	±1 hour

*Approximate runtimes only. Actual runtime varies depending on load, inverter efficiency, appliance start-up requirements and battery condition. Always fully charge the unit before use.
